Model: 16.86 (10x70mm CC) Shredder with Baler
About This Shredder:
The flagship of the Intimus range — 16.50 S-class shredding throughput with an integrated baler, for the largest destruction operations.
The INTIMUS 16.86 (10x70mm, with Baler) combines the 16.50 S’s bulk shredding throughput with an integrated 80kN baler, compressing output directly into 60-80kg bales at approx. 550 kg/h. At 1,256kg it is the heaviest, highest-capacity machine in the Intimus line.
Built for records warehouses, national archives and large-scale destruction service providers who need both volume and a hands-off, bin-free operation.
Security level P-2, 10x70mm cross cut — coarse by design, prioritising throughput for bulk routine destruction.
Features:
- Integrated 80kN hydraulic baler — 60-80kg bales at approx. 550 kg/h.
- Security level P-2, 10x70mm cross cut.
- 500mm working width, widest format in the range.
- 400V three-phase, continuous industrial duty.
- The highest-capacity machine in the Intimus range at 1,256kg.
- German-built.
Technical Specification:
- Sheet capacity (70gsm): 520 sheets (70gsm)
- Shred type: Cross Cut
- Shred size (mm): 10x70mm
- Security Level: P-2 (DIN 66399 / ISO 21964)
- Working width: 500 mm / A2
- Throughput: 550 kg/h
- Bale dimensions (L x W x H): 800 x 600 x 500 mm (60-80kg bale weight)
- Machine size: 1200 x 2830 x 1550 mm (W x D x H)
- Net Weight: 1256 kg
- Motor capacity: 7500 W
- Power supply: 400V / 50Hz
- Machine warranty: 1 Year
Technical specification
| Cut Type | Cross Cut |
|---|---|
| Shred Size | 10x70mm |
| Sheet Capacity | 520 sheets (70gsm) |
| Security Level | P-2 |
| Insertion Width | 500 mm / A2 |
| Noise Level | 61 dB |
| Machine Weight | 1256 kg |
| Machine Dimensions | 1200 x 2830 x 1550 mm (W x D x H) |
| Warranty | 1 Year |
